Description
Product Description
CPU Specifications
- Total Cores12
- Total Threads24
- Max Turbo Frequency3.00 GHz
- Processor Base Frequency2.10 GHz
- Cache16.5 MB L3 Cache
- Max # of UPI Links2
- TDP85 W
Memory Specifications
- Max Memory Size (dependent on memory type)768 GB
- Memory TypesDDR4-2400
- Maximum Memory Speed2400 MHz
- Max # of Memory Channels6
- ECC Memory Supported ‡Yes
Expansion Options
- Scalability2S
- PCI Express Revision3.0
- Max # of PCI Express Lanes48
Package Specifications
- Sockets SupportedFCLGA3647
- TCASE76°C
- Package Size76.0mm x 56.5mm
Advanced Technologies
- Intel® Optane™ Memory Supported ‡No
- Intel® Speed Shift TechnologyYes
- Intel® Turbo Boost Max Technology 3.0 ‡No
- Intel® Turbo Boost Technology ‡2.0
- Intel® Hyper-Threading Technology ‡Yes
- Intel® Transactional Synchronization ExtensionsYes
- Intel® 64 ‡Yes
- Instruction Set ExtensionsIntel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
- # of AVX-512 FMA Units1
- Enhanced Intel SpeedStep® TechnologyYes
- Intel® Volume Management Device (VMD)Yes
Security & Reliability
- Intel vPro® Platform Eligibility ‡Yes
- Intel® AES New InstructionsYes
- Intel® Trusted Execution Technology ‡Yes
- Execute Disable Bit ‡Yes
- Mode-based Execute Control (MBEC)Yes
- Intel® Virtualization Technology (VT-x) ‡Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡Yes
