| Brand |
Uniview |
| Range |
Easy |
| Inputs for IP cameras |
LAN port up to 8 channels |
| IP compatible cameras |
UNIVIEW, ONVIF |
| Audio |
1 RCA output |
| Video outputs |
1 HDMI 4K, 1 VGA |
| Video compression format |
Ultra265 / H.265 / H.264 |
| Display resolution |
3840×2160@30Hz, 1920x1080p@60Hz, 1920x1080p@50Hz, 1600×1200@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz |
| Total bandwidth |
64 Mbps downstream / 48 Mbps upstream |
| Main Stream recording |
4K / 5Mpx 4Mpx 3Mpx / 1080p / 960p 720p / D12CIF / CIF |
| Decoding |
1CH@4K or 1CH@5Mpx or 2CH@4Mpx or 4CH@3Mpx or 4CH@1080p or 8CH@720p |
| Intelligent functions |
Face Detection, Intrusion Detection, Line Crossing Detection, Audio Detection |
| External Backup |
USB / HDD USB memory |
| Internal memory |
1 SATA HDD 3.5″ of up to 6 TB (not included) |
